Original Plans for St Machar Cathedral Organ

Plans drawn up by Ellis & Wilson in February 1891 were submitted to the Standing Committee of the Heritors of the Parish of Old Machar at their meeting in Aberdeen on 16 March 1891, and are now in the National Records of Scotland. Copies of two of the Crown Copyright documents are reproduced under the NRS restricted use conditions. Click on the images to see the full sized copies.

Front Elevation and Plan of St Machar Cathedral Organ 1891

Front Elevation and Plan

South Side Elevation of St Machar's Cathedral Organ 1891

South Side Elevation

St Machar's Cathedral Organ Console

The Current Console
